APPLICATIONS
Extended distance touring cables for Ethernet and Ethernet-based protocols. Ideal for use with the Neutrik Ethercon. Polyethylene cross member and TPV jacket ensure protection for the solid conductors in dynamic use. Suitable for Gigabit and 100 Mbit to a maximum recommended channel link distance of 105 metres (U/UTP) or 77 metres (SF/UTP).
Part Nos. & Descriptions
| Part No. | Description | Max. Reel Length |
| 268-660-000 | Van Damme TourCat Cat 6 Solid U/UTP | 500 M |
| 268-662-000 | Van Damme TourCat Cat 6 Solid SF/UTP | 500 M |
Mechanical Specification
| Conductors | 1 x 0.574 mm bare oxygen free copper |
| Conductor size | 1 x 0.574 mm, 0.259 mm2, AWG 23 |
| Insulation | Low density polyethylene (PE-LD) |
| Insulation diameter | 1.05 ± 0.13 mm |
| Screen 1 (268-662-000) | Aluminium/Polyester foil |
| Screen 2 (268-662-000) | 0.10 x 16 x 11 tinned copper braid |
| Jacket material | Thermoplastic Vulcanizate |
| Overall diameters: | |
| 268-662-000 SF/UTP | 8.00 ± 0.30 mm |
| Bend radius | 10 x overall diameter |
Electrical Specification
| Impedance | 1 – 100 MHz 200 – 250 MHz |
100 ± 15 Ω 100 ± 22 Ω |
| Velocity of Propagation | 69 % nominal | |
| Attenuation: | ||
| 268-662-000 SF/UTP | 100 MHz 250 MHz |
19.0 dB/100 m (worst pair) 28.2 dB/100 m (worst pair) |
DOWNLOADS
| Cable Name | Van Damme TourCat Cat 6 Solid SF/UTP |
|---|
Brand
Van Damme Cables
