Van Damme Digitour AES/EBU & DMX 110 Ohm Pre-jacketed Cable

The Van Damme Digitour cables are black jacketed versions of the Green Series AES Microphone cable and 2, 4, 8 and 12 pair pre-jacketed multicores, introduced in response to user requests. Green Series is often used for DMX512 control signals, but lacks the unobtrusive jacket colour often needed by the Lighting and Presentation markets. Low capacitance and stable characteristic impedance make these cables ideal for DMX512 as well as AES/EBU and analogue audio signals.

Call For Price - 1800 833 4228

Van Damme Cables
SKU Digitour Series AES DMX Category Tags , ,
Request Price

APPLICATIONS

  • DMX transmission for lighting fixtures and devices
  • Digital audio signal transmission for installations, equipment racks and devices
  • Any 100 to 110 Ohm balanced data application such as RS422, RS485, and timecode

Application Notes

  • Suitable for analogue balanced audio and AES/EBU as well as DMX512
  • 2, 4, 8 and 12 way multicores have 26AWG conductors for reduced overall diameter; single cable has 24AWG conductors
  • Ultra-pure oxygen free copper for outstanding sonic integrity

Part Nos. & Description



Part Number Description Overall Diameter (mm) Max. Reel Length
268-412-000 Van Damme Digitour DMX/AES 2 pair multicore 7.70 500m
268-414-000 Van Damme Digitour DMX/AES 4 pair multicore 9.20 500m
268-418-000 Van Damme Digitour DMX/AES 8 pair multicore 12.20 500m
268-482-012 Van Damme Digitour DMX/AES 12 pair multicore 15.00 500m
268-482-000 Van Damme Digitour DMX/AES Microphone cable 6.20 500m



DOWNLOADS

Technical Specification PDF
