APPLICATIONS
Live sound touring multipin cables from 4 – 48 pairs. Remote stagebox systems. Installation use where a braided overall screen offers a significant advantage over having pre-jacketed pairs – e.g. in a hazardous environment or deteriorated ducting. Any longer length multicore and multipin application where frequent rigging and de-rigging occurs. Presentations use where a neutral jacket colour is required.
Part Nos. & Description
| Part Number | Description | Overall Diameter (mm) | Max. Reel Length |
| 268-104-000 | Van Damme Black Series Tour Grade 4 pair multicore | 9.60 | 500m |
| 268-108-000 | Van Damme Black Series Tour Grade 8 pair multicore | 12.30 | 500m |
| 268-112-000 | Van Damme Black Series Tour Grade 12 pair multicore | 13.00 | 500m |
| 268-116-000 | Van Damme Black Series Tour Grade 16 pair multicore | 14.50 | 500m |
| 268-124-000 | Van Damme Black Series Tour Grade 24 pair multicore | 17.20 | 500m |
| 268-132-000 | Van Damme Black Series Tour Grade 32 pair multicore | 19.00 | 500m |
| 268-148-000 | Van Damme Black Series Tour Grade 48 pair multicore | 22.80 | 500m |
Mechanical Specification
| Conductors | 28 x 0.10 mm bare ultra-pure oxygen-free copper |
| Conductor size | 28 x 0.10 mm, 0.22 mm2, AWG 24/28 |
| Insulation | Polypropylene |
| Screen type | 24 µm Aluminium/Polyester Foil >150% coverage Clear polyester overwrap |
| Drain wire | 19 x 0.12 mm tinned ultra-pure oxygen-free copper |
| Overall Construction | |
| Separator | Soft tape |
| Overall braid | Tinned copper wire, < 80% coverage |
| Jacket material | Flexible PVC composite, Jet Black RAL 9005 |
| Bend Radius | 10 x overall diameter |
Electrical Specification
| Resistance | Conductor | < 90 Ohm/km |
| Insulation | > 5000 MOhm/km | |
| Capacitance | Core to core Core to screen |
81 pF/m 160 pF/m |
