APPLICATIONS
- Matt black jacket for on stage use.
- 1.50 mm² and 2.50 mm² conductors for lower power applications.
- 4.00 mm² and 6.00 mm² conductors for high power passive speakers and subs.
Part Nos. & Description
| Part Number | Description | Max. Reel Length |
| 268-515-000 | Van Damme Black Series Tour Grade 2 x 1.50 mm2 twin-axial | 500m |
| 268-525-000 | Van Damme Black Series Tour Grade 2 x 2.50 mm2 twin-axial | 500m |
| 268-545-000 | Van Damme Black Series Tour Grade 2 x 4.00 mm2 twin-axial | 500m |
| 268-526-000 | Van Damme Black Series Tour Grade 2 x 6.00 mm2 twin-axial | 500m |
General Specification
| Conductors | Bare ultra-pure oxygen-free copper |
| Insulation | PVC, Red and Blue |
| Jacket material | Flexible PVC composite Jet Black RAL 9005 |
| Working Voltage | 300/500 V |
| Bend radius | 10 x overall diameter |
Characteristics by Part No.
| Part Number | Conductor Size | Overall Diameter (mm) | Stranding | Resistance (Ohm/km) |
| 268-515-000 | 1.50 mm2 | 6.50 | 30 x 0.25 mm | 12.30 |
| 268-525-000 | 2.50 mm2 | 7.60 | 50 x 0.25 mm | 7.30 |
| 268-545-000 | 4.00 mm2 | 12.40 | 50 x 0.30 mm | 4.50 |
| 268-526-000 | 6.00 mm2 | 14.00 | 84 x 0.30 mm | 3.10 |
